日本Y.S高压树脂绝缘毯简介：
1、树脂绝缘毯用来保护电气作业人员在带电作业时避免误触带电体、设备或带电线路。
2、树脂绝缘毯具有柔软，重量轻的特性，有多种规格可用于大部分的包覆，广为带电作业人员推荐使用。
3、采用EVA的材料制作，具有较长的使用和存储寿命。
日本Y.S高压树脂绝缘毯规格参数：
|
ITEM NO. |
SIZE |
A.C.PROOF TEST |
A.C.MAXIMUM USE |
|
YS203-11-01 |
600×1000mm |
20KV/1min |
7000V |
|
YS203-11-02 |
680×800mm |
20KV/1min |
7000V |
|
YS203-11-03 |
680×1200mm |
20KV/1min |
7000V |
|
YS203-11-04 |
900×1000mm |
20KV/1min |
7000V |
|
YS203-11-05 |
800×1000mm |
20KV/1min |
7000V |
|
YS203-11-06 |
600×1000mm |
20KV/1min |
7000V |
|
YS203-11-20 |
700×1500mm |
20KV/1min |
7000V |
|
YS241-01-01 |
600×1000mm |
20KV/3min |
17000V |
|
YS241-01-02 |
680×800mm |
20KV/3min |
17000V |
|
YS241-01-03 |
680×1200mm |
20KV/3min |
17000V |
|
YS241-01-04 |
800×1000mm |
20KV/3min |
17000V |
|
YS241-01-05 |
900×1000mm |
20KV/3min |
17000V |
|
YS242-01-01 |
600×1000mm |
30KV/3min |
26500V |
|
YS242-01-02 |
680×800mm |
30KV/3min |
26500V |
|
YS242-01-03 |
680×1200mm |
30KV/3min |
26500V |
|
YS242-01-04 |
800×1000mm |
30KV/3min |
26500V |
|
YS242-01-05 |
900×1000mm |
30KV/3min |
26500V |
